Achieving Tunable Mode Splitter and Omnidirectional Absorber by Semiconductor Photonic Crystal
By
Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)469-472
Abstract
The properties of one-dimensional (1D) photonic crystals (PCs) composed of the semiconductor (GaAs) and dielectric layers are theoretically investigated by the transfer matrix method (TMM). Due to the Voigt effect, the dielectric constant of the semiconductor could be modified in different modes and frequency ranges. If the frequency range of the incident wave is larger than the plasma frequency, TE and TM modes of the incident wave will be absorbed in a wide incident angle. TM wave will be absorbed but TE wave will be reflected while the frequency range is less than the plasma frequency. By varying the external magnetic field, the absorption of semiconductor can be tuned. The proposed PCs have a reconfigurable application to design a tunable omnidirectional absorber and mode splitter at same time.
Citation
Bo-Rui Bian, Guowen Ding, Xiang-Kun Kong, Hai-Ming Li, Shaobin Liu, and Hai Feng Zhang, "Achieving Tunable Mode Splitter and Omnidirectional Absorber by Semiconductor Photonic Crystal," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)469-472
References

1. John, Sajeev, "Strong localization of photons in certain disordered dielectric superlattices," American Physical Society (APS), Vol. 58, No. 23, 2486–2489, June 1987.
doi:10.1103/physrevlett.58.2486        Google Scholar

2. Yablonovitch, Eli, "Inhibited Spontaneous Emission in Solid-State Physics and Electronics," American Physical Society (APS), Vol. 58, No. 20, 2059–2062, May 1987.
doi:10.1103/physrevlett.58.2059        Google Scholar

3. Landy, N. I., S. Sajuyigbe, J. J. Mock, D. R. Smith, and W. J. Padilla, "Perfect Metamaterial Absorber," American Physical Society (APS), Vol. 100, No. 20, May 2008.
doi:10.1103/physrevlett.100.207402        Google Scholar

4. Gong, Yongkang, Xueming Liu, Hua Lu, Leiran Wang, and Guoxi Wang, "Perfect absorber supported by optical Tamm states in plasmonic waveguide," Optica Publishing Group, Vol. 19, No. 19, 18393, September 2011.
doi:10.1364/oe.19.018393        Google Scholar

5. Shi, Yaocheng, "A COMPACT POLARIZATION BEAM SPLITTER BASED ON A MULTIMODE PHOTONIC CRYSTAL WAVEGUIDE WITH AN INTERNAL PHOTONIC CRYSTAL SECTION," The Electromagnetics Academy, Vol. 103, No. 5., 393–401, 2010.
doi:10.2528/pier10040402        Google Scholar

6. Hu, M.H., J.Z. Huang, R. Scarmozzino, M. Levy, and R.M. Osgood, "Tunable Mach-Zehnder polarization splitter using height-tapered Y-branches," Institute of Electrical and Electronics Engineers (IEEE), Vol. 9, No. 6, 773–775, June 1997.
doi:10.1109/68.584986        Google Scholar

7. Soldano, L.B., A.I. de Vreede, M.K. Smit, B.H. Verbeek, E.G. Metaal, and F.H. Green, "Mach-Zehnder interferometer polarization splitter in InGaAsP/InP," Institute of Electrical and Electronics Engineers (IEEE), Vol. 6, No. 3, 402–405, March 1994.
doi:10.1109/68.275500        Google Scholar

8. Xu, Chun, Dezhuan Han, Xin Wang, Xiaohan Liu, and Jian Zi, "Extrinsic photonic crystals: Photonic band structure calculations of a doped semiconductor under a magnetic field," AIP Publishing, Vol. 90, No. 6, February 2007.
doi:10.1063/1.2437723        Google Scholar

9. Zhang, Hai-Feng, Shao-Bin Liu, Xiang-Kun Kong, Bo-Rui Bian, and Yi Dai, "Omnidirectional photonic band gap enlarged by one-dimensional ternary unmagnetized plasma photonic crystals based on a new Fibonacci quasiperiodic structure," AIP Publishing, Vol. 19, No. 11, November 2012.
doi:10.1063/1.4765063        Google Scholar

10. Feng, Liang, Xiao-Ping Liu, Yue-Feng Tang, Yan-Feng Chen, Jian Zi, Shi-Ning Zhu, and Yong-Yuan Zhu, "Tunable negative refraction in a two-dimensional active magneto-optical photonic crystal," American Physical Society (APS), Vol. 71, No. 19, May 2005.
doi:10.1103/physrevb.71.195106        Google Scholar

11. Kong, Xiang-Kun, Shao-Bin Liu, Hai-Feng Zhang, Shen-Yun Wang, Bo-Rui Bian, and Yi Dai, "Tunable Bistability in Photonic Multilayers Doped by Unmagnetized Plasma and Coupled Nonlinear Defects," Institute of Electrical and Electronics Engineers (IEEE), Vol. 19, No. 1, 8401407–8401407, January 2013.
doi:10.1109/jstqe.2012.2202092        Google Scholar

12. Xu, Chun, Xinhua Hu, Yizhou Li, Xiaohan Liu, Rongtang Fu, and Jian Zi, "Semiconductor-based tunable photonic crystals by means of an external magnetic field," American Physical Society (APS), Vol. 68, No. 19, November 2003.
doi:10.1103/physrevb.68.193201        Google Scholar

13. Zhou, Jun, Li Jin, and Edwin Yue-Bun Pun, "Tunable multichannel nonreciprocal perfect absorber based on resonant absorption," Optica Publishing Group, Vol. 37, No. 13, 2613, July 2012.
doi:10.1364/ol.37.002613        Google Scholar
.
