The Optimized Electrode between a SMPM Connector and a Microstrip for High Frequency Applications

Yaw-Dong Wu,

Yaw-Dong Wu

National Kaohsiung University of Applied Sciences, Taiwan, R.O.C.

Homepage

Jau-Ji Jou,

Jau-Ji Jou

National Kaohsiung University of Applied Sciences, Taiwan

Homepage

Hong-Lu Lin,

Hong-Lu Lin

National Kaohsiung University of Applied Sciences, Taiwan

Homepage

Tien-Tsorng Shih,

Tien-Tsorng Shih

National Kaohsiung University of Applied Sciences, Taiwan, R.O.C.

Homepage

Cheng-Ying Wu

National Kaohsiung University of Applied Sciences, Taiwan

Homepage

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)149-152

Abstract

In this paper, a smaller and cheaper novel Subminiature Modular Plug-in Mini (SMPM) connector has been used to replace a K-type connector. The SMPM connector is installed on the top of printed circuit board (PCB) and soldering with an electrode to reduce the trace of a microstrip and to maintain the high frequency performance. Three designs of the PCB electrode have been simulated and verified experimentally. The optimized impedance mismatch of the soldering point between a SMPM connector and the PCB electrode is controlled within a range of ±2-Ohm. The 3-dB bandwidth of the whole setup including two SMPM connectors and a 2.5-cm long microstrip is above 25-GHz. This optimization can be used in designing high-speed PCB for the application of 100GBASE Ethernet.

Citation

Yaw-Dong Wu, Jau-Ji Jou, Hong-Lu Lin, Tien-Tsorng Shih, and Cheng-Ying Wu, "The Optimized Electrode between a SMPM Connector and a Microstrip for High Frequency Applications," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)149-152
