A Novel Monopulse Microstrip Antenna Array with Compound Feed Network
By
Feng-Wei Yao,
    avatar

    Feng-Wei Yao

    Shanghai Key Laboratory of Electromagnetic Environment Effects for Aerospace Vehicle, China

    Homepage

Xing-Zuo Dai,
    avatar

    Xing-Zuo Dai

    Shanghai Key Laboratory of Electromagnetic Environment Effects for Aerospace Vehicle, China

    Homepage

Yuan-Bo Shang,
    avatar

    Yuan-Bo Shang

    Shanghai Key Laboratory of Electromagnetic Environment Effects for Aerospace Vehicle, China

    Homepage

Xiao-Qing Tian,
    avatar

    Xiao-Qing Tian

    Shanghai Key Laboratory of Electromagnetic Environment Effects for Aerospace Vehicle, China

    Homepage

Li-Li Zhu
    avatar

    Li-Li Zhu

    Shanghai Key Laboratory of Electromagnetic Effect for Aerospace Vehicles, China

    Homepage

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)132-135
Abstract
In this paper, a novel feed network design is presented, with which every microstrip line array of antenna is fed at the edge side with the middle of the row shorted and in E-plane the adjacent subarrays are fed with 180 degrees phase difference. This proposed feed network can suppress the near coupling problem in traditional monopulse microstrip antenna array design. Furthermore in order to minish the loss of substrate and microstrip feed line, a waveguide one- plane feed network and waveguide comparator are used, which is connected with every line array by SMA-waveguide connector. The simulated results have demonstrated that the −19 dB side- lobe level for the sum pattern and 32 dB null depth for the difference pattern have achieved.
Citation
Feng-Wei Yao, Xing-Zuo Dai, Yuan-Bo Shang, Xiao-Qing Tian, and Li-Li Zhu, "A Novel Monopulse Microstrip Antenna Array with Compound Feed Network," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)132-135
