TM Wave Mode Analysis of Circular Dielectric Resonator with Anisotropic Permittivity
By
Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)230-233
Abstract
This paper presents the theoretical analysis of transverse magnetic (TM) wave mode for circular dielectric resonator with anisotropic permittivity. The analysis which is em- phasized on its resonant frequency is required to investigate specific properties of resonator in TM wave mode which are useful for microwave application. By introducing the anisotropic per- mittivity, the resonator is expected to have the property with unique characteristic compared to the conventional one. To determine the resonant frequency of resonator for TM wave mode, Maxwell’s equations with proper boundary condition are applied for circular waveguide that en- capsulates an anisotropic circular dielectric resonator. The anisotropic permittivity is established by assuming the different values of relative permittivity in each axis of cylindrical coordinate, i.e., ²ρ , ²φ and ²z . The analysis result shows that the circular dielectric resonator with anisotropic per- mittivity in z axis, i.e., propagation direction, has significantly changed the resonant frequencies of TM wave mode which can be applicable for resonance mode selection.
Citation
Andriyan Bayu Suksmono, Hepi Ludiyati, and Achmad Munir, "TM Wave Mode Analysis of Circular Dielectric Resonator with Anisotropic Permittivity," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)230-233
