Substrate Integrated Waveguide Frequency Reconfigurable Filter Controlled by Magnetic Field
By
Yu Jian Cheng,
    avatar

    Yu Jian Cheng

    University of Electronic Science and Technology of China, China

    Homepage

Qiu Dong Huang,
    avatar

    Qiu Dong Huang

    University of Electronic Science and Technology of China, China

    Homepage

Xiao Liang Liu
    avatar

    Xiao Liang Liu

    University of Electronic Science and Technology of China, China

    Homepage

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)2533-2536
Abstract
In this work, a novel upper and lower sideband tunable SIW bandpass ferrite filter is presented. With the application of an external magnetic bias on the ferrite slabs, the lower sideband of the filter can be adjusted from 8.8 GHz to 10.7 GHz and the upper sideband can be tuned from 9.3 GHz to 12.0 GHz. Compared to previously reported frequency tunable SIW filters, the proposed filter offers a relatively wide tuning range and flexibly reconfigurable abilities while dramatically reducing the complexity of external control circuit.
Citation
Yu Jian Cheng, Qiu Dong Huang, and Xiao Liang Liu, "Substrate Integrated Waveguide Frequency Reconfigurable Filter Controlled by Magnetic Field," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)2533-2536
