A Novel Miniaturized Frequency Selective Surface with Stable Performances

By

Hou Zhang,

Hou Zhang

Air Force Engineering University, China

Yongfan Lin,

Yongfan Lin

Air Force Engineering University, China

Rui Wu,

Rui Wu

Air Force Engineering University, China

Zhiyong Xu,

Zhiyong Xu

Air Force Engineering University, China

Zimu Yang

Zimu Yang

Air Force Engineering University, China

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1647-1650

Abstract

A novel stable miniaturized band-reject frequency selective surface (FSS) is pro- posed in this paper. Compared to previous miniaturized structures, the dimension of the proposed FSS unit cell is only 0.050λ0 × 0.050λ0 where λ0 represents the wavelength of the resonant fre- quency. And characteristics of the new structure are stable with respect to waves with different polarizations and incident angles. Simulation of structure with different parameters is also taken, and the results demonstrate the claimed performance and the possibility of better miniaturiza- tion by changing the parameters of the structure. Thus, the proposed structure is suitable for practical application in limited space.

Citation

Hou Zhang, Yongfan Lin, Rui Wu, Zhiyong Xu, and Zimu Yang, "A Novel Miniaturized Frequency Selective Surface with Stable Performances," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1647-1650

References

Download Full Article (PDF ) Wire media illustration
