High Gain Electromagnetically Coupled Stacked Circular Disk Patch Antenna for Wideband Application
By
Dagang Fang,
    avatar

    Dagang Fang

    Nanjing University of Science and Technology, China

    Homepage

Wen Wu,
    avatar

    Wen Wu

    Nanjing University of Science and Technology, China

    Homepage

Nagendra Prasad Yadav
    avatar

    Nagendra Prasad Yadav

    Hubei Polytechnic University, China

    Homepage

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1701-1706
Abstract
Bandwidth enhancement behavior of an electromagnetically coupled stacked cir- cular disk patch antenna is presented theoretically. The effects of feed point locations, radius of parasitic disk, and air gap-spacing are analyzed to achieve optimum conditions for wideband operation. The antenna shows a bandwidth as large as twelve times of that of a single circular patch antenna. The radiation patterns of the antenna are similar to those of the single disk antenna. The theoretical results are in reasonable agreement with the simulated ones from IE3D.
Citation
Dagang Fang, Wen Wu, and Nagendra Prasad Yadav, "High Gain Electromagnetically Coupled Stacked Circular Disk Patch Antenna for Wideband Application," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1701-1706
References

Download Full Article (PDF ) Wire media illustration
