Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)1131-1134
Abstract
The delay time of echo generated by the moving target simulator is discrete, and
the moving trace of simulated target is discontinuous. In order to solve this problem, firstly, the
radar digital signal processor must adjust the range gate, and the range error will be limited
within one range cell. Then the rest error cannot be removed but can be adjusted by phase
pre-compensation in simulator. The idea is that let the phase of simulated target be equal to the
one of the real target at sampling time. After the phase pre-compensation, a real continuously
moving target will be generated and the problem will be solved. Then MATLAB simulation of
the method is done for linear frequency modulation radar system. The simulated results can be
used to validate the effectiveness of the method.
Citation
Chao Wang,
Naichang Yuan,
Deping Zhang,
and
Chang Zhu,
"Continuously Moving Target Simulator Design," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)1131-1134
