Design of Dual Cross Dipole Antennas with Dual Frequencies and Dual Circularly-polarized
By
Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)1911-1913
Abstract
An integrated antennas are presented with dual frequencies and dual circularly- polarized (CP) in a common aperture. The proposed integrated antennas are consisted of dual crossed dipole antennas (CDA) with stacked structure, which used 90◦ self-phase shifting struc- tures in both CDAs for CP wave achieving by adjusting the proportion of the orthogonal arm lengths for 90◦ phase difference forming. The upper CDA covers 4.7% relative bandwidth from 1.55 GHz to 1.625 GHz with VSWR less than 2 and axial ratio (AR) less than 3 dB of left-hand CP (LHCP) and the nether CDA covers 3.4% relative bandwidth of 2.44∼2.525 GHz for right-hand CP (RHCP).
Citation
Lei Chang, Yu-Feng Wang, and Yufeng Yu, "Design of Dual Cross Dipole Antennas with Dual Frequencies and Dual Circularly-polarized," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9,Page(s)1911-1913
