A Compact Dual Band Band-pass Filter Using a New Topology of Transmission Line Metamaterial
By
Jacques David,
    avatar

    Jacques David

    National Polytechnic Institute of Toulouse, France

    Homepage

Akram Boubakri,
    avatar

    Akram Boubakri

    Innov'Com Laboratory, Tunisia

    Homepage

Fethi Choubani,
    avatar

    Fethi Choubani

    University of Carthage, Tunisia

    Homepage

Tan Hoa Vuong
    avatar

    Tan Hoa Vuong

    University of Toulouse, France

    Homepage

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1918-1921
Abstract
In this paper, we introduce a dual-band band pass filter based on a transmission line metamaterial. The unit cell of this metamaterial was loaded with shunt inductor and series capacitor. Once simulated with HFSS, our band pass filter revealed two operational frequencies 5.8 GHz and 8.7 GHz, making it a good candidate for many microwave applications and especially for RADAR.
Citation
Jacques David, Akram Boubakri, Fethi Choubani, and Tan Hoa Vuong, "A Compact Dual Band Band-pass Filter Using a New Topology of Transmission Line Metamaterial," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1918-1921
References

Download Full Article (PDF ) Wire media illustration
