A Novel Phase Measurement System Based on Six Port Reflectometer and LabVIEW
By
Jiajun Bian,
    avatar

    Jiajun Bian

    East China Normal University, China

    Homepage

Tailei Wang,
    avatar

    Tailei Wang

    East China Normal University, China

    Homepage

Shouzheng Zhu
    avatar

    Shouzheng Zhu

    East China Normal University, China

    Homepage

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)625-628
Abstract
A novel six port reflectometer (SPR) measurement system based on LabVIEW and a simple calibration method used to reducing the drastic complication of the calibration algorithms is proposed in this paper. The efficiency of manual device measuring is improved by this novel measurement system. This new system can be operated easily. The amplitude and phase’s experimental and theory results are provided to demonstrate the performance of the developed SPR.
Citation
Jiajun Bian, Tailei Wang, and Shouzheng Zhu, "A Novel Phase Measurement System Based on Six Port Reflectometer and LabVIEW," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)625-628
