Novel Design of H-plane Bandpass Waveguide Filters Using Complementary Split Ring Resonators
By
Djordje Mirkovic,
    avatar

    Djordje Mirkovic

    University of Oklahoma, USA

    Homepage

Milka M. Potrebic,
    avatar

    Milka M. Potrebic

    University of Belgrade, Serbia

    Homepage

S. Stefanovski,
    avatar

    S. Stefanovski

    University of Belgrade, Serbia

    Homepage

D. Tosic
    avatar

    D. Tosic

    University of Belgrade, Serbia

    Homepage

Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1963-1968
Abstract
In this paper, a novel design of bandpass waveguide filters, using complementary split ring resonators is proposed. Resonators are implemented as inserts in a form of metal plates, with properly shaped slots, in the transverse planes of the rectangular waveguide. Filter response has been investigated for various parameters of the resonator and its position. Simple design of dual-band filter is introduced, using resonators attached to the top and bottom waveguide wall. Also, second-order dual-band filter is proposed.
Citation
Djordje Mirkovic, Milka M. Potrebic, S. Stefanovski, and D. Tosic, "Novel Design of H-plane Bandpass Waveguide Filters Using Complementary Split Ring Resonators," Proceedings of 2015 Photonics & Electromagnetics Research Symposium, Prague, July 6 - 9，Page(s)1963-1968
